| Nº | parte | nombre chino | nombre |
| 1 | DZ9100410054 | 前轴 | frontal eje |
| DZ9100410056 | 前轴 | frontal eje | |
| DZ9100410058 | 前轴 | frontal eje | |
| DZ9100410067 | 前轴 | frente eje | |
| DZ9100410068 | 前轴 | frente eje | |
| DZ9100410071 | 前轴 | frontal eje | |
| DZ9100410072 | 前轴 | frontal eje | |
| DZ9100410073 | 前轴 | frontal eje | |
| DZ9100410075 | 前轴 | frente eje | |
| DZ9100410188 | 前轴 | frontal eje | |
| DZ9100410190 | 前轴 | frontal eje |
| Nº | parte | nombre chino | nombre |
| 2 | 81.44215.0016 | 止推垫圈 | tope Arandela |
| 3 | 81.92901.0066 | 锁紧螺母 | traba tuerca |
| 4 | 81.44312.0009 | 轮毂帽 | rueda tapa |
| 5 | Q218B1040TF2 | 内六角圆柱头螺钉 | Hex.screw |
| 6 | 06.32499.0016 | 圆锥滚子轴承 | cónicos rodamiento |
| 7 | Q1811660TF2 | 六角法兰面带齿螺栓 | perno |
| 8 | 1.90004E + 11 | 车轮螺母 | rueda tuerca |
| 9 | DZ9100410029 | 轮毂 | eje |
| 10 | DZ9100410106 | 车轮螺栓 | rueda perno |
| 11 | 06.32499.0081 | 圆锥滚子轴承 | cónicos rodamiento |
| 12 | 06.56289.0267 | 轴密封圈 | Junta de eje |
| 13 | 81.52403.0008 | ABS 脉冲齿圈 | ABS anillo |
| 14 | DZ9100440030 | 制动盘 | Freno disco |
| DZ9100410115 | 制动盘 | disco | |
| 15 | DZ9100410114 | 制动钳总成(左) | freno pinza de freno Assembly(left) |
| DZ9100440040 | 制动钳总成(左) | freno pinza Assembly(left) | |
| DZ9100440077 | 制动钳总成(左) | freno pinza Assembly(left) | |
| 16 | DZ9100410118 | 制动钳总成(右) | freno pinza Assembly(right) |
| DZ9100440050 | 制动钳总成(右) | freno pinza Assembly(right) | |
| DZ9100440078 | 制动钳总成(右) | freno pinza Assembly(right) | |
| 17 | DZ9100360301 | 制动气室(左) | freno Chamber(left) |
| 18 | DZ9100360302 | 制动气室(右) | de freno Chamber(right) |
| 19 | 81.46711.6725 | 转向横拉杆 | manejo de pista barra |
| 81.46701.6901 | 转向横拉杆 | manejo de pista barra | |
| 20 | DZ9100410211 | 盘式转向节(左) | freno de disco nudillo ( izquierdo ) |
| DZ9100410213 | 盘式转向节(左) |
freno de disco nudillo ( izquierdo ) | |
| DZ9100410215 | 盘式转向节(左) | disco freno nudillo ( izquierdo ) | |
| DZ9100410217 | 盘式转向节(左) | disco freno nudillo ( izquierdo ) | |
| 21 | DZ9100410212 | 盘式转向节(右) | disco freno nudillo ( derecho ) |
| DZ9100410214 | 盘式转向节(右) | disco freno nudillo ( derecho ) | |
| DZ9100410216 | 盘式转向节(右) | freno de disco nudillo ( derecho ) | |
